Big Tex 25DU
Call for Quote
(903) 577-7418Mount Pleasant, TX
The 25DU Tandem Dual Gooseneck Dump Trailer is the trailer that dreams are made of - as long as youre dreaming about hauling massive payloads with ease. Designed to handle the needs of professionals in construction, landscaping, and other demanding industries, the 25DU is meant to take on the toughest loads thanks to its reinforced construction and worry-free dual tires. Heavy machinery? No problem, its equipped with ramps. Huge loads of trash, sand or gravel? A tall dump box with 4-foot sides thats capable of a 45 degree dump angle makes that task a breeze. With a load capacity of 17,830 lbs, the 25DU is a versatile powerhouse of a trailer thatll have your back through thick and thin.
- Overview
- Features/Specifications
- Standard/Optional Equipment
- Financing
Overview
Big Tex 25DU
- Availability:
- On Order
- Axle Config:
- Tandem Dual
- Hitch Type:
- Gooseneck
- Category:
- Dump Trailers
- Year:
- 2021
- Condition:
- New
- Material:
- Steel
- Warranty:
- Factory Warranty Included
- Color:
- Black
Features/Specifications
Features
| Axle | (2) 10,000# Dual Wheel Oil Bath Electric Brakes |
|---|---|
| Jack | Dual 12,000# Side Wind Drop Legs |
| Neck | 12" I-Beam |
| Tire | ST235/80 R-16 Load Range E Dual |
| Floor | 10 Gauge Smooth Steel |
| Wheel | 16" x 6"; Black Dual Wheel 8 Bolt |
| Finish | Superior Quality Finish is Applied for a Highly Decorative and Protective Finish. |
| Lights | L.E.D. D.O.T. Stop, Tail, Turn & Clearance |
| Coupler | 2-5/16" Square Adjustable Crank Type (30K) |
| Fenders | Double Square Broke Diamond Plate |
| G.V.W.R. | 25,900# |
| Elec. Plug | 7-Way RV |
|---|---|
| Hitch Type | Gooseneck |
| Main Frame | 12" x 16# I-Beam |
| Suspension | Heavy Duty 30,000# Adjustable |
| Finish (Prep) | Steel is Cleaned to Ensure a Professional Smooth Finish. |
| Safety Chains | 3/8" Grd. 70 w/Safety Latch Hook (2 each) |
| Dump Body Sides | 48" Tall Sides (12 Gauge) |
| Dump Body Top Rail | 4" x 2" Rectangular Tubing |
| G.A.W.R. (Ea. Axle) | 10,000# |
| Dump Body Crossmembers | 3" Channel, 16" Centers |
Specifications
Big Tex 25DU Tandem Dual Gooseneck Dump Trailer
| Model | Description |
|---|---|
| 25DU-20 | 92" x 20' Tandem Dual Gooseneck Dump |
Trailer Weights & Capacities
| Length | Empty Weight | Payload | Box Capacity |
|---|---|---|---|
| 20' | 8,070# | 16,930# | 23.70 Cubic Yards |
Standard/Optional Equipment
Standard Equipment
- Square, Adjustable Crank 2-5/16" Gooseneck Coupler (30K)
- Dual 12,000# Drop-Leg Jacks (Side Wind)
- Lockable Pump & Battery Box Mounted Between Jacks
- 48" Tall, 12 Gauge Sides w/Formed Channel Supports
- 10 Gauge Steel Floor
- Fully Formed Tarp Shroud on Front
- J-Hooks on Sides & Rear for Tarp Control
- Stakepockets Along Sides
- Self Contained Electric/Hydraulic Scissor Hoist
- Power Up/Gravity Down Hydraulic Pump
- 12V Interstate Deep Cycle Battery
- 110V On-Board Battery Charger (5 Amp)
- Premium Brand Axles
- Cambered, Oil Bath Axles
- Forward Self Adjusting Electric Brakes on All Hubs
- Grommet Mount Sealed Lighting
- L.E.D. Lighting Package
- Sealed, Modular Wiring Harness
- Complete Break-A-Way System
- Zip Breakaway Cable
- 4" x 2" Rec. Tubing Top Rail on Dump Bed
- Double Rear Doors
- (4) 5/8" D-Rings Inside Bed to Secure Equipment
- Mudflaps
- Spare Tire Mount
- Radial Tires
- Spare Tire & Wheel - Standard Equipped
Optional Equipment
| Category | Description |
|---|---|
| AXLE | 12,000# Axle Upgrade (GVWR Remains 25,900#) |
| BODY | Removable Deck on the Neck-Bolt On (8 W x 6 L) |
| CARGO CONTROL | Crank Style Roll Tarp |
| CARGO CONTROL | Industrial Roll Tarp w/Side Flaps |
| JACK | Dual 2-Speed Landing Gear |
| JACKS | Dual Elec/Hyd 12,000# Jacks by Stillwell |
| POWER | 5 Watt Solar Charger |
| POWER | Wireless Remote |
| RAMPS | 8 Slide In Ramps |
| TIRE/WHEEL | Tire Updgrade (ST215/75 R-17.5 LR-H Dual) Includes Spare |
| TIRE/WHEEL | Tire Upgrade (ST235/85 R-16 LR-G Dual) Includes Spare |
